Full Band 360 Drone Detection System Covering 300MHz To 6GHz With 10km Range

Drone Detector Full-Band 360° Detection System Covering 300MHz To 6GHz With 10km Detection Range

Introduction

Drone Detector Full-Band 360° Detection System Covering 300MHz To 6GHz With 10km Detection Range is a highly portable, easy-to-operate shield device engineered for advanced UAV defense. Equipped with multi-frequency strike capabilities, it neutralizes potential threats while providing detailed UAV reconnaissance and identification functions, ensuring effective protection against unauthorized drones in diverse operational environments, and ensuring critical operational success.

Parameters

1. Defensive Interference: Jams signals across 900MHz, 1.5GHz, 2.4GHz, and 5.8GHz.

2. Powerful Interference: Targeted design for Mavic 3 UAV, disrupting communication and navigation systems.

3. Navigation Signal Shield: Blocks GPS L1/L2, BeiDou B1, GLONASS, and Galileo signals.

4. Convenience: Lightweight, portable design for easy transport and use.

5. Display: 3.5” display showing battery life and device status.

6. Handle: Ergonomic handle to reduce fatigue during operation.

7. Safety: IP55 protection with undervoltage, overcurrent, overtemperature, and radiation protection.

8. Interference Bands: 840-930MHz, 1.555-1.625GHz, 2.400-2.485GHz, 5.725-5.850GHz.

9. Working Duration: ≥1 hour.

10. Power Consumption: ≤30W.

11. Interference Radius: 1-2km.

12. Weight: 3.5kg.

13. Dimensions: 300mm × 260mm × 140mm.

Features

Multi-Frequency Bands Detection

• Detects and blocks FPV-specific frequencies (e.g., 1.2GHz, 2.4GHz, 5.8GHz) used for video transmission, remote control, and GPS navigation.

• Supports customizable frequency bands (e.g., 433MHz, 915MHz) to counter diverse drone models.

Portable & Lightweight Design

• Ultra-Compact: Weighs 3.5kg with ergonomic grip
• Rugged Build: IP55-rated Waterproof and dustproof housing, military-grade aluminum alloy frame for outdoor durability.
• Long Battery Life: Built-in 6000mAh Li-Po battery provides ≥2 hours of continuous operation; supports USB-C fast charging.

Operations Modes

1) Detect mode

 Click DETN to enter the detection page, when a drone is detected. The screen will display the current UAV model and frequency band;

2) STRIKE mode:

 Select STRIKE in to the jamming page. After selecting the jamming mode, press the button on the handle and the jamming system will work, jamming the drones within range.
