X Band Airspace Surveillance And Tracking Drone Detection Radar System 5-10km

Function

Descriptions

UAV detection

Detection spectrum bandwidth: 70 MHZ - 6GHZ, detection focus on the 433Mhz, 868Mhz, 915Mhz, 2.4Ghz, 5.2Ghz, 5.8Ghz

FPV Detection:300Mhz-6.2Ghz Analog Signal of FPV Drones

Simultaneous screening number of UAV: ≧150pcs

The lowest detection height: ≤0 meters

Detection rate: ≧99.99 %s

Drones Location

For UAVs with Remote ID (China GB42590-2023, US ASTM F3411-22a, EU ASD-STAN PrEN4709-002) and Drone ID (such as DJI Mavic2, Mavic3, air3s, Matrice4, etc., some require network decryption), it can parse detailed information such as drone location and pilot location.

White and Blacklist

The Systemcan identify ≧ 400 different model UAV including DJI series drones,and it has the autonomous learning ability.

The Systemcan carry on the accurate identification of target, in-depth analysis of UAV signal, the identification of unique ID, and the black and whitelist to distinguish.

Whitelist and a blacklist can be set for different targets of the same position, same frequency band, same manufacturer, same type of UAV respectively.

Defensive Interference

PS The Systemhas interference capabilities of 900MHz, 433Mhz; 1.5ghz, 2.4ghz, 5.8ghz; 5.2Ghz and other customized frequency bands, and covers most of the UAV communication available in market.

Remote OAM

After turning on the fully self-movable defense, it can enter unattended mode, detect, and strike autonomously. And a variety of OAM features are available when used with the remote server, including firmware updating, resetting, status inquiry, self-testing, parameter configuration, and more.

GPS

The Systemcan detect its current position using its built-in GPS.

Networking

The Systemcan network multiple devices through the cloud server, observe the online/abnormal status of each device, and control the device remotely through the mobile terminal (mobile phone IPAD), including but not limited to viewing the operating interface of the device system, receiving alarm information, viewing the black and whitelist, and turning on defense functions.

Data security

Use certificate management and data encryption between the equipment and server to ensure data reliability and security.
